Description
| GPU Engine Specs: | |
|---|---|
| CUDA Cores | 640 |
| Graphics Clock-Base Clock (MHz) | 1354 |
| Boost Clock (MHz) | 1455 |
| Memory Specs: | |
| Memory Clock | 7Gbps |
| Standard Memory Config | 2GB |
| Memory Interface | GDDR5 |
| Memory Interface Width | 128-bit |
| Memory Bandwidth (GB/sec) | 168.2 |
| Bus Support | PCI-E 3.0 X16 |
| Feature Support: | |
| NVIDIA Ansel | Yes |
| NVIDIA G-SYNC™-Ready | Yes |
| NVIDIA GameStream™-Ready | Yes |
| NVIDIA GPU Boost™ | 3.0 |
| Microsoft DirectX | 12 API with feature level 12_1 |
| Vulkan API | Yes |
| OpenGL | 4.5 |
| OS Certification | Windows 7-10, Linux, FreeBSDx86 |
| Display Support: | |
| Mulit Monitor | Yes |
| Maxmium Digital Resolution | 7680×4320 at 60 Hz RGB 8-bit with dual DisplayPort connectors or 7680×4320 at 60 Hz YUV420 8-bit with on DisplayPort 1.3 connector |
| HDCP | 2.2 |
| Standard Display Connectors | Dual Link DVI-D, HDMI 2.0b, DisplayPort 1.4 |
| InternalAudio Input for HDMI | Internal |
| Standard Graphics Card Dimensions: | |
| Length | 211mm |
| Height | 99.8mm |
| Width | 1-slot |
| Thermal and Power Spec: | |
| Minimum System Power Requirement (W) | 400 |
| Supplementary Power Connectors | NA |
| Accessories: | |
| Driver CD Kit | Yes |
