Description
| Product Name | MasterBox E500L (Side Window Panel Version) | |
| Product Number | MCB-E500L-KA5N-S00 (Blue) MCB-E500L-KA5N-S01 (Red) MCB-E500L-KA5N-S02 (Silver) |
|
| Available Color | Black | |
| Materials | Steel, Plastic | |
| Dimensions (LxWxH) | 490 x 203 x 426mm | |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX | |
| Expansion Slots | 7 | |
| Drive Bays | 5.25″ | 1 |
| 3.5″ | 2 | |
| 2.5″ | 2 | |
| I/O Port | USB 3.0 x 2, Audio In / Out | |
| Pre-installed Fan(s) | Front | 120mm x 1 LED fan |
| Rear | 120mm x 1 Black fan | |
| Fan Support | Front | 120mm / 140mm x 2 |
| Top | 120mm x 2 ** | |
| Rear | 120mm x 1 | |
| Radiator Support | Front | 120 / 140 / 240 / 280mm radiator |
| Rear | 120mm radiator (Need to install fan first) | |
| Clearances | CPU Cooler | 157mm |
| PSU | 220mm | |
| GPU | 399mm | |
| Cable Routing | Behind MB Tray | 22mm |
| Dust Filters | Front, Top, Bottom | |
| Power Supply | Bottom mount, ATX | |
| Power Supply Cover | Included | |
| Carton dimension (L x W x H) | 470 x 227 x 555mm* | |
| EAN Code | 4719512070031 – MCB-E500L-KA5N-S00 (Blue) 4719512070048 – MCB-E500L-KA5N-S01 (Red) 4719512070055 – MCB-E500L-KA5N-S02 (Silver) |
|
| UPC Code | 884102042546 – MCB-E500L-KA5N-S00 (Blue) 884102042553 – MCB-E500L-KA5N-S01 (Red) 884102042560 – MCB-E500L-KA5N-S02 (Silver) |
|
| Note: * 1 case package per carton ** please check motherboard component height whether if ok to install fan on top |
||
